The above CAD model is similar to the product you will receive.  The white machine was just the prototype.  After using the splitter we have decided to add extra features like a torsion axle, larger hydraulic tank, bigger pump, large rod cylinder and our tow away from the pile frame.  Towing into the pile just makes for extra work for the customer since they have remove the wood before moving the splitter.  When we get closer to production we will be posting update pictures of this unit.  If you have any questions please feel free to call or message us.



Birch Series

The Birch Series is our entry level splitter designed for re-splitting and small round processing.  With features like a steel plate frame, 20 gallon hydraulic tank, 17 tons of splitting force, autocycle valve, wedge lift, log lift, EZ-Slide grate, AR400 wear surfaces and our 3-year frame warranty make this the best re-split machine on the market today.  Shoot us a call today to order yours!

​

Specifications

​

  • Steel plate frame (3 year warranty on frame)

  • AR400 wear surfaces

  • 17 tons of splitting force

  • 20" stroke (24" available)

  • 24gpm hydraulic pump

  • Honda GX390 (electric start available)

  • 3.5 second cycle time

  • 24 gallon hydraulic tank

  • Torsion axle

  • 5.30x12 Tires

  • Travel speed 60mph

  • Log lift

  • Wedge Lift

  • Ez- Slide log grate

  • 4 way wedge is standard (6 way is optional)

  • 2" ball

​

​
